用途：农业灌溉·泵·工程排水·工业配套·水泥泵车·吸排水结构
特征：双层PVC 中间涤纶纤维·外层 PVC 加强筋
使用温度:-4° F(-20℃ ) to 150° F(+65℃ )
Nominal Dimension | Size | Pressure at 23℃ | Weight | Standard Length | ||
Inches | I.D. Ø | O.D. Ø | W.P. | B.P. | M/Kg | M |
(mm) | (mm) | Bar | Bar | |||
2” | 51 | 66 | 7 | 20 | 1.2 | 30 |
2-1/2” | 64 | 76 | 7 | 20 | 1.7 | 30 |
3” | 77 | 95 | 6 | 18 | 2.2 | 30 |
4” | 102.5 | 121 | 5 | 16 | 3.2 | 12/15/18/30 |
5” | 127.5 | 152 | 5 | 15 | 4.5 | 12/15/18/20 |
6” | 154.5 | 180.5 | 5 | 15 | 5.8 | 12/15/18/20 |
8” | 203.5 | 232 | 4 | 12 | 8.6 | 12 |
