APPLICATIONS:
Applicable to the industry and agricuture, engineering,fisheries aquaculture, aquatic breeding areas, under normaltemperature, usually working pressure of liquid transportation.
Features:This product is soft, flexible, nontoxic,good quality.
Applicable temperature:-15℃ -65 ℃ .
Nominal Dimension | Size | Length | W.P. | B.P. | Weight | Volume | ||
lnch | I.D. mm | O.D. mm | M | Bar | Bar | Kg/Roll | M3 | |
1/4" | 6 | 8 | 100 | 1.5 | 5 | 3 | 0.015 | |
5/16" | 8 | 10 | 100 | 1.5 | 4 | 3.8 | 0.019 | |
3/8" | 10 | 12 | 100 | 1.5 | 4 | 4.7 | 0.026 | |
1/2" | 12 | 15 | 50 | 1 | 4 | 4.3 | 0.019 | |
5/8" | 15 | 18 | 50 | 1 | 3 | 5.2 | 0.03 | |
3/4" | 19 | 22 | 50 | 1 | 3 | 6.5 | 0.03 | |
1" | 25 | 30 | 50 | 1 | 3 | 14.6 | 0.068 | |
1-1/4" | 32 | 38 | 40 | 1 | 3 | 17.8 | 0.113 | |
1-1/2" | 38 | 44 | 40 | 1 | 3 | 20.8 | 0.15 | |
2" | 50 | 58 | 40 | 1 | 2.5 | 36.6 | 0.262 | |
