Applications:
The product is used for conveying water, oil, gas under normal working condition in the factory, farm, ship, building and family. The hose used for foodstuffs is made of special materials. It is light, flexible, durable, non-toxic, without odor, transparent. It can also be used for conveying milk, beverage, distilled liquor, beer, jan and other foods in vending machines, ice machine and refrigerators, etc.
Characteristics:
It is flexible, transparent, durable, non-toxic, without odor, anti-erosion and adaptable to high pressure condition. By adding colorful symbol lines on the surface of the hose, it looks more beautiful.
Temperature: -5℃ ~65℃
Nominal Dimension | Size | Length | W.P. | B.P. | Weight | Volume | ||
lnch | I.D. mm | O.D. mm | M | Bar | Bar | Kg/Roll | M3 | |
13/64" | 5 | 9 | 100 | 8 | 25 | 5.8 | 0.012 | |
1/4" | 6 | 10 | 100 | 10 | 30 | 6.6 | 0.015 | |
1/4" | 6 | 11 | 100 | 10 | 30 | 8.7 | 0.018 | |
1/4" | 6 | 12 | 100 | 10 | 30 | 11.1 | 0.019 | |
5/16" | 8 | 12 | 100 | 10 | 30 | 8.2 | 0.019 | |
5/16" | 8 | 13 | 100 | 10 | 30 | 10.8 | 0.025 | |
5/16" | 8 | 14 | 100 | 10 | 30 | 13.6 | 0.029 | |
3/8" | 9 | 13 | 100 | 9 | 27 | 9 | 0.025 | |
3/8" | 9 | 14 | 100 | 9 | 27 | 11.8 | 0.029 | |
13/32" | 10 | 14 | 100 | 8 | 24 | 10.2 | 0.029 | |
13/32" | 10 | 15 | 100 | 8 | 24 | 12.9 | 0.032 | |
13/32" | 10 | 16 | 100 | 8 | 24 | 16 | 0.038 | |
1/2" | 12 | 16 | 100 | 7 | 21 | 11.5 | 0.038 | |
1/2" | 12 | 17 | 100 | 7 | 21 | 14.9 | 0.042 | |
1/2" | 12 | 18 | 100 | 9 | 27 | 18.5 | 0.045 | |
1/2" | 13 | 17 | 100 | 6 | 18 | 12.3 | 0.042 | |
1/2" | 13 | 18 | 100 | 6 | 18 | 15.9 | 0.045 | |
1/2" | 13 | 19 | 100 | 8 | 24 | 19.7 | 0.052 | |
35/64" | 14 | 19 | 100 | 7 | 21 | 17 | 0.052 | |
35/64" | 14 | 20 | 100 | 7 | 21 | 21 | 0.057 | |
5/8" | 15 | 19 | 50 | 6 | 18 | 7 | 0.03 | |
5/8" | 15 | 20 | 50 | 7 | 21 | 9 | 0.03 | |
5/8" | 15 | 21 | 50 | 8 | 24 | 11.1 | 0.03 | |
5/8" | 16 | 20 | 50 | 5 | 15 | 7.4 | 0.03 | |
5/8" | 16 | 21 | 50 | 7 | 21 | 9.5 | 0.03 | |
5/8" | 16 | 22 | 50 | 8 | 24 | 11.7 | 0.031 | |
45/64" | 18 | 24 | 50 | 6 | 18 | 13 | 0.035 | |
3/4" | 19 | 23 | 50 | 4 | 12 | 8.6 | 0.043 | |
3/4" | 19 | 24 | 50 | 4 | 12 | 11.1 | 0.043 | |
3/4" | 19 | 25 | 50 | 7 | 21 | 13.6 | 0.045 | |
3/4" | 19 | 26 | 50 | 8 | 24 | 16.2 | 0.05 | |
25/32" | 20 | 25 | 50 | 6 | 18 | 11.6 | 0.046 | |
25/32" | 20 | 26 | 50 | 6 | 18 | 14.2 | 0.048 | |
25/32" | 20 | 27 | 50 | 7 | 21 | 16.9 | 0.051 | |
25/32" | 20 | 28 | 50 | 7 | 21 | 19.7 | 0.057 | |
7/8" | 22 | 27 | 50 | 5 | 15 | 12.6 | 0.056 | |
7/8" | 22 | 28 | 50 | 6 | 18 | 15.4 | 0.058 | |
7/8" | 22 | 29 | 50 | 6 | 18 | 18.4 | 0.058 | |
7/8" | 22 | 30 | 50 | 7 | 21 | 21.4 | 0.058 | |
1" | 25 | 30 | 50 | 4 | 12 | 14.1 | 0.068 | |
1" | 25 | 31 | 50 | 5 | 15 | 17.3 | 0.072 | |
1" | 25 | 32 | 50 | 5 | 15 | 20.5 | 0.077 | |
1" | 25 | 33 | 50 | 6 | 18 | 23.9 | 0.079 | |
1-1/4" | 32 | 39 | 40 | 4 | 12 | 20.4 | 0.119 | |
1-1/4" | 32 | 40 | 40 | 5 | 15 | 23.7 | 0.119 | |
1-1/4" | 32 | 41 | 40 | 5 | 15 | 27 | 0.103 | |
1-1/4" | 32 | 42 | 40 | 5 | 15 | 30.4 | 0.103 | |
1-1/2" | 38 | 45 | 40 | 4 | 12 | 23.9 | 0.151 | |
1-1/2" | 38 | 46 | 40 | 4 | 12 | 27.6 | 0.151 | |
1-1/2" | 38 | 48 | 40 | 4 | 12 | 35.4 | 0.155 | |
1-3/4" | 45 | 55 | 40 | 4 | 12 | 30.9 | 0.217 | |
2" | 50 | 58 | 40 | 3 | 9 | 26.7 | 0.198 | |
2" | 50 | 59 | 40 | 4 | 12 | 30.3 | 0.198 | |
2" | 50 | 60 | 40 | 4 | 12 | 33.9 | 0.198 | |
2" | 50 | 62 | 40 | 4 | 12 | 41.5 | 0.209 | |
2-1/2" | 64 | 78 | 40 | 4 | 12 | 51.5 | 0.304 | |
3" | 75 | 90 | 40 | 4 | 12 | 51 | 0.35 | |
